Specifications
Power Rating
- Prime Power: 500 kVA
- Standby Power: Up to 550 kVA
- Power Factor: 0.8
Engine Specifications
- Engine Make: Caterpillar (CAT)
- Engine Type: 4-Stroke, Turbocharged & Aftercooled
- No. of Cylinders: 6 / 8 Cylinder (model dependent)
- Cooling System: Water-cooled
- Fuel Type: Diesel
Alternator Details
- Type: Brushless, Single / Double Bearing (model dependent)
- Phase: 3 Phase
- Voltage: 415V
- Frequency: 50 Hz
Fuel Consumption (Approx.)
- 500 kVA: 80–90 L/hr
Fuel consumption may vary depending on load conditions.
Acoustic & Noise Level
- CPCB compliant acoustic enclosure (where applicable)
- Noise Level: Approx. 75–80 dB @ 1 meter
- Low vibration, stable operation
Control Panel
- Advanced digital control panel (AMF / Manual)
- Real-time monitoring of voltage, current, frequency, and engine parameters
- Synchronization capability (optional)
Safety Features
- Overload Protection
- Short Circuit Protection
- Low Oil Pressure Shutdown
- High Engine Temperature Shutdown
- Emergency stop system
Build & Design
- Heavy-duty industrial base frame
- Integrated or external fuel tank options
- Weather-resistant canopy / open skid configuration
- Easy maintenance access
Applications
- Large Industrial Plants
- Infrastructure Projects
- Commercial Complexes
- Data Centers & Critical Backup
- Continuous Power Requirements
Key Benefits
- High-capacity performance for demanding operations
- Reliable and stable power output
- Fuel-efficient for large-scale usage
- Suitable for continuous and parallel operations
